Circuito integrato

Circuito integrato

Lineare integrated circuit TV, Synchron-Dem., Video-Verst./Amp.

Lineare integrated circuit Breitb.-/Wideb. Amp., PQ--0,5W(9V)

Lineare integrated circuit Dual, Breitb./Wideband Amp., ..120MHz

Universal Operational Amplifier, single Vs:ø20V Vu:70dB Vo:ø7V Vi0:1mV

Lineare integrated circuit 6-Di-Array, S, 5V, 25mA, 1ns, 0,65pF

Lineare integrated circuit FM-ZF, Dem., NF-V/Tr

Lineare integrated circuit 5x NPN-Trans., 20V, 50mA, -55..+125°C

Lineare integrated circuit Quad, Uni AC Verst./Amp., 16V

Lineare integrated circuit Quad, AC Verst./Amp., NF-V, +16V

Lineare integrated circuit Dual, Breitb./Wideband Amp., ..120MHz

Lineare integrated circuit TV-Ton-ZF, FM-ZF, Dem, NF-Tr

Lineare integrated circuit HiFi, FM-ZF-Limiter, Dem., NF-V

Tansconductance Operational Amplifier, single Vs:ø18V Vi0:0.3mV f:2Mc Cmr:110dB

Lineare integrated circuit 7x NPN Trans.-Array, 20V, 0,1A, 0,75W

Lineare integrated circuit 7x NPN Trans.-Array, 20V, 0,1A, 0,75W

Lineare integrated circuit ER+:1.8..26V Iom:12mA Vin:30V

Lineare integrated circuit FM MPX Stereo-Decoder, Ucc--10..16V

Lineare integrated circuit AM Radio, Ucc--9V

Lineare integrated circuit CTV, PAL Chroma-Prozessor

Lineare integrated circuit Vs:16V Vu:110dB Vo:13.3/0V Vi0:8mV

BiMOS Operational Amplifier, single Vs:ø18V Vu:100dB Vo:13/14V Vi0:5mV

Lineare integrated circuit BCD--7-Segment Decoder, +7V

Analog to digital converter, periphery  Dual Slope, 3-Digit MPX BCD Output, 7V

Lineare integrated circuit HiFi, FM-ZF, Dem., AFC, AGC(progr.)

BiMOS Operational Amplifier, single  Vs:ø18V Vu:115dB Vo:ø13.5V f:1.2Mc

BiMOS Operational Amplifier, single  Vs:22V Vu:100V/mV Vo:ø9.7V Vi0:0.8mV

Lineare integrated circuit TV, HA-Synchr., Osc.

Control Unit Processor ITT - TV

Circuito integrato ITT

Central Control Unit for LOEWE - TV
